Solar Water Pump

Home › Solar Water Pump
High Efficiency Solar Pumping Solutions

Heavy-DutySolar Water Pumps for Agriculture & Industry

Eliminate electricity & diesel costs with Northsun’s high-head AC & DC Submersible and Surface Solar Water Pumps (1 HP – 10 HP) powered by smart MPPT controller drives.

  • Zero Electricity Bills
  • 25-Year Panel Warranty
  • PM-KUSUM Subsidy Approved
INTERACTIVE TOOL

Solar Pump Capacity & Price Estimator

Select your required Horsepower (HP) capacity to view instant solar panel requirement, water output, and direct pricing details.

SELECT PUMP CAPACITY
10 HP System
High Volume Irrigation & Industrial
1 HP 2 HP 3 HP 5 HP 7.5 HP 10 HP
☀️
Includes high-efficiency Mono PERC Solar Modules with IP68 Submersible/Surface Motor Set.
SOLAR PANEL ARRAY
10,000 Watts (10.0 kW)
High Efficiency DCR / Mono PERC
DAILY WATER OUTPUT
3,70,000 Liters / Day
Average Peak Sun Hours
MAX HEAD DEPTH
100 – 160+ Meters
Submersible / Borewell Range
CONTROLLER TYPE
Industrial Heavy VFD
Dry Run & Over-Voltage Protect
ESTIMATED SYSTEM PRICE
₹3,200,000*
*Excluding GST, mounting structure & local piping
Ready for Dispatch
Get Direct WhatsApp Quote for 10 HP →
Engineering Excellence

Technical Specifications Matrix

Standard 1 HP to 10 HP solar water pump configurations.

Zero Electricity & Diesel Costs

Operates 100% on free solar energy. Recovers total system investment within 1.5 to 2 years compared to diesel generator pumping setups.

Smart MPPT Controller

Advanced Variable Frequency Drive (VFD) automatically adjusts motor speed according to sunlight intensity, ensuring continuous water delivery even on cloudy days.

25-Year Panel Performance Warranty

High-grade Mono PERC / DCR solar panels certified under BIS and MNRE guidelines with long-term guaranteed performance output.

PM-KUSUM Subsidy Approved

Eligible for state and central government subsidies under the PM-KUSUM scheme for farmers, agricultural societies, and water user associations.

Dry Run & Overload Protection

Smart sensors protect motor windings from dry running when water table drops, voltage spikes, and phase imbalance.

Turnkey Installation Support

Full on-site civil structure installation, panel mounting, electrical wiring, testing, and dedicated pan-India service support.

Engineering Data

Technical Specifications Matrix

Standard 1 HP to 10 HP solar water pump configurations.

Pump Capacity (HP) Solar Array (kW) Max Head Depth Daily Water Discharge Controller Type Est. Price (Ex. GST)
1 HP DC / AC 1.2 kW (1,200W) 15 – 30 Meters 38,000 LPD MPPT Intelligent Drive ₹52,000
2 HP DC / AC 2.0 kW (2,000W) 25 – 50 Meters 75,000 LPD MPPT Intelligent Drive ₹82,000
3 HP AC / DC 3.0 kW (3,000W) 40 – 70 Meters 1,20,000 LPD Vector VFD MPPT ₹1,15,000
5 HP AC 3-Phase 5.0 kW (5,000W) 60 – 100 Meters 1,90,000 LPD High-Capacity VFD ₹1,78,000
7.5 HP AC 3-Phase 7.5 kW (7,500W) 80 – 130 Meters 2,80,000 LPD Industrial Solar VFD ₹2,45,000
10 HP AC 3-Phase 10.0 kW (10,000W) 100 – 160+ Meters 3,70,000 LPD Industrial Heavy VFD ₹3,20,000
Frequently Asked Questions

Questions About Solar Water Pumps

Will a solar water pump work on cloudy days or during monsoon?
Yes. Northsun solar pumps utilize advanced MPPT (Maximum Power Point Tracking) controllers that can run the motor even at reduced solar irradiance. While peak discharge occurs during direct sunlight (10 AM to 4 PM), the system will still pump water at lower speeds during overcast weather.

Yes! With our customized Solar Variable Frequency Drive (VFD) Retrofit Kit, your existing 3-phase AC submersible motor can be connected directly to a solar panel array without replacing your pump set.

Under the PM-KUSUM Scheme (Component B), eligible farmers can get up to 60% subsidy (30% Central + 30% State) on solar pump capacities up to 7.5 HP. Northsun provides full paperwork and MNRE-compliant equipment support.

The solar PV panels come with a 25-year performance warranty. The MPPT VFD controller and motor set have a design operational life of 8 to 12 years with minimal maintenance required.
